CAT7 S/FTP Lan Cable

Shielded Cat7 Ethernet Lan Cable, 1000ft (305m), 23AWG Solid Pure Bare Copper Wire,1000MHz, PVC/LSZH

Features:

Up to 1000MHz with 1/2.5/5/10G-T Speed, Support PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)

Structure cabling for horizontal and building backbone

Compliant with ISO/IEC11801, ANSI/TIA-568.2-D Fire and Safety Standards

Specification :

Cable Type	Category 7	Shielding Type	S/FTP
Cable Jacket	PVC /LSZH	Cable Length	1000ft (305m)
Reference Bandwidth	1000MHz	Data Rate Support	1/2.5/5/10G-T
Wire Gauge	23AWG	Conductor Type	Bare Copper
Putup Type	Reel	Number of Conductors	4 Pair
Conductor Diameter (mm)	0.56 ± 0.005	Cable Outer Diameter (mm)	7.6 ± 0.50
Maximum Installation Tension (N)	110	Bend Radius (mm)	32.4
Cable Color	various	Standard	ISO/IEC11801, ANSI/TIA-568.2-D
Operating Temperature	-15 to 75°C	Installation Temperature	-10 to 60°C
